JCC Fireguard GU10 IP65 Downlight Chrome
Product Code JC010016/CH
Available for Delivery only, change to Fast Delivery Service
£7.90
exc VAT
£9.48 : inc VAT
£9.48
inc VAT
£7.90 : exc VAT
The JCC Fireguard JC010016/WH Next Generation fire-rated IP65 fixed downlight is an exemplary choice for both contractors and homeowners seeking a blend of functionality and modern design. This downlight features a sleek chrome bezel that enhances its aesthetic appeal, making it an ideal addition to any contemporary home. Designed for streamlined installation, the downlight's shortened can allows for use in shallower voids, while its narrowed and tapered shape facilitates easier entry into ceilings. This innovative design not only improves the mobility of the spring clips but also significantly reduces installation time, making it a practical solution for various lighting needs.
The JCC Fireguard downlight is engineered with safety and longevity in mind, featuring insulation coverability that promotes airflow and ventilation for the LED, thereby extending its lifespan. With a fire rating of 30, 60, and 90 minutes, this downlight plays a crucial role in fire prevention, offering peace of mind to homeowners by helping to contain the spread of fire. The flexibility of the Fireguard allows users to choose their preferred GU10 LED lamp during installation, with options for varying lamp colours and wattages to suit individual preferences. Additionally, the bezel can be easily fitted using a simple twist and lock mechanism, making future lamp and bezel changes hassle-free.
Key Features:
- IP65 chrome bezel included
- Designed for GU10 LED lamps - lamps not included
- Cut-Out: 74mm
- Part B fire rating compliant - 30, 60, and 90 minute fire rating
- Airtight (Part C)
- Acoustic rated (Part E)
- Tested for use in solid, I-Joist and steel open web joist ceilings
- Thermally tested for use with mineral wool insulation
- Ultra-fast press fit
- Loop in/out terminal
- Easy twist and lock bezel replacement
- Minimum void: 150mm
- Spring clip fixing
- IP Rating: IP65
- LED compatible
- Wattage: 7W LED maximum
- Construction: Die-cast aluminium
- Class: Class 1, earth cable required
- Compatible with bulbs A+ to E
- Diameter: 87mm
- Depth: 108.7mm
- Weight: 0.264kg
- Standards: BS EN 60598-2-1, 2-2, CE Mark, WEEE symbol
- Product code: JC010016/CH
- JCC Warranty: 2 years
For any questions about this product or to learn more about Lightplan's design services, feel free to reach out. You can contact us by phone at 0208 342 7009, through our contact form, or by emailing sales@lightplan.co.uk.
Would you prefer to speak with a lighting expert face-to-face? Visit your nearest Lightplan showroom, where our lighting experts are ready to assist.
| Product Downloads | JCC Fireguard JC010016CH Data Sheet |
|---|---|
| Model Number | JC010016/CH |
| Brand | JCC |
| Range | Fireguard Next Generation |
| Light Fitting | LED GU10 (not included) |
| Fitting Type | Fixed Downlight |
| Mounting | Recessed Ceiling |
| Fire Rating | 30/60/90 Minute |
| Bezel Colour | Chrome |
| Bezel Included | Yes |
| Install Location: | Bedroom, Kitchen, Hallway, Living Space |
| Max Wattage | 7W LED |
| Dimmable | Lamp Dependent |
| Energy Rating | A+ to E |
| Connector | Press Fit Terminals |
| Class | I, Earth Required |
| Dimensions (Diameter x D): | 87mm x 108.7mm |
| Diameter | 87mm |
| Cut Out | 74mm |
| Minimum Ceiling Void | 150mm |
| Type of Use | Indoor |
| RIm Material | Die-cast Aluminium |
| Method of Fix | Spring Clips |
| IP Rating | IP65 |
| Weight | 0.171kg |
| Voltage | 230V |
| Warranty | 2 Years Standard |
| Building Regulations | Part B, C and E |
| Standards | BS EN 60598-2-1, 2-2 |
| CE Marked | Yes |
