The JCC JC1001/NB V50 downlight is a sophisticated lighting solution designed to enhance both functionality and aesthetics in various settings. This dimmable LED downlight offers the flexibility of choosing between two elegant bezel finishes—white chrome or brushed nickel—allowing for seamless integration into any interior design scheme. This model is engineered to meet stringent safety standards, boasting a fire rating of 30, 60, and 90 minutes in compliance with Part B and Parts L1 and L2 regulations, ensuring peace of mind in both residential and commercial applications.
One of the standout features of the JC1001/NB is its colour switchable capability, which allows users to select between warm white and cool white light during installation. This versatility is particularly beneficial for those who may wish to adapt their lighting to suit different room styles or moods over time. The integrated 7.5W LED delivers an impressive lumen output of either 600 or 650 lumens, depending on the chosen colour temperature, making it an energy-efficient option that does not compromise on brightness.
For any questions about this product or to learn more about Lightplan's design services, feel free to reach out. You can contact us by phone at 0208 342 7009, through our contact form, or by emailing sales@lightplan.co.uk.
Would you prefer to speak with a lighting expert face-to-face? Visit your nearest Lightplan showroom, where our lighting experts are ready to assist.
| Model Number | JC1001NB |
| Brand | JCC |
| Range | V50 LED Downlight |
| Product Type | Dimmable Fire-Rated LED Downlight |
| Environment | Indoor |
| Suitable For Zones | Zone 1 & Zone 2 |
| Product Shape | Round |
| Light Source | LED |
| Dimmable | Yes |
| Light Distribution Detail | 60°C |
| Luminaire Circuit Wattage | 7.5W |
| Product Aperture Size | 70mm |
| Mounting | Recessed |
| Energy Rating | F |
| Class | II |
| LED Life | 51000 Hours |
| Diameter | 84mm |
| Depth | 68mm |
| Product Weight | 0.28kg |
| Minimum Void Requirement | 50mm |
| Maximum Ceiling Depth | 30mm |
| Method Of Fix | Push Fit with Twist |
| Input Electrical Connections | Push Fit Terminals LEN Loop In/Loop Out |
| Max. Number in Run | 20 |
| IP Rating | IP65 |
| Insulation Coverage | Loosely Cover with Mineral Wool Insulation |
| Warranty | 2 years, extended to 3 year commercial or 5 year domestic warranty when registered within the first year of purchase |
| Voltage Rating | 230 |
| Output Voltage Max/Range (VDC) | 36 |
| Operating Frequency | 50/60Hz |
| Actual Lumen Output | 600/650 |
| Lumens Per Ciruit Watt | 80/87 |
| Colour Rendering Index | 80-89 |
| Light Output Ratio | 100% LOR |
| Photometry Available | Yes |
| CRI: Ra | >80 |
| Color Temperature | Switchable Between 3000K/4000K (Warm White/cool White) |
| Dimming Protocol Compatibility | Triac |
| Constant Current or Constant Voltage | Constant Current (CC) |
| Beam Angle | 60° |
| Operating Temperature | 0 to 26°C |
| Primary Material | Steel |
| Lens | Polycarbonate |
| Heat Sink | Aluminium |
| Driver Housing | Polycarbonate |
| Rim/Attachment | Die-Cast Aluminium |
| Voltage Rating | 230 |
| EAN Barcode | 5052544081224 |
| Manufactured in Accordance to | BS EN 60598:2015, 2-1, 2-2 |
| CE Marked | Yes |
| UKCA Marked | Yes |
| Accredited Members | LIA, ISO9001-2015, ISO14001-2015 |
