The JCC Lighting V50 downlight, model number JC1001/CH, is a refined lighting solution designed to enhance both aesthetics and functionality in a range of environments. Featuring a sleek chrome bezel, this downlight integrates seamlessly into any contemporary decor, adding a touch of elegance whilst ensuring optimal illumination. The integrated dimmable LED technology allows users to adjust the brightness to their liking, making it an ideal choice for both residential and commercial spaces.
A key feature of the JCC V50 downlight is its colour switchable capability, enabling users to select either warm white or cool white light upon installation. This flexibility is particularly advantageous for those who may wish to tailor their lighting to suit varying room styles or personal preferences over time. The energy-efficient 7.5W integrated LED delivers an impressive light output of either 600 or 650 lumens, depending on the chosen colour temperature, ensuring that spaces are well-lit without excessive energy consumption.
For any questions about this product or to learn more about Lightplan's design services, feel free to reach out. You can contact us by phone at 0208 342 7009, through our contact form, or by emailing sales@lightplan.co.uk.
Would you prefer to speak with a lighting expert face-to-face? Visit your nearest Lightplan showroom, where our lighting experts are ready to assist.
| Product Downloads | JCC V50 Specification Sheet, JCC V50 Wiring Instructions |
|---|---|
| Model Number | JC1001/CH |
| Brand | JCC |
| Range | V50 |
| Lighting Type | LED CCT Downlight |
| Light Source | LED |
| Mounting | Recessed Ceiling |
| LED Colour | 3000K or 4000K |
| Lumen Output | 600 (WW) / 650 (CW) |
| Lumen Efficacy | 80lm/W / 87lm/W |
| CRI rating | 80 |
| Beam Angle | 60 Degrees |
| Class | II |
| Lifetime Expectancy | 51,000 Hours |
| Bezel Colour | Chrome |
| Bezel Included | Yes |
| Install Location: | Bedroom, Kitchen, Hallway, Living Space |
| Dimensions (Diameter x D): | 84mm x 67mm |
| Diameter | 84mm |
| Cut Out | 70mm |
| Minimum Void | 50mm |
| Max No. In Run | 20 |
| Type of Use | Indoor |
| Body Material | Steel |
| Diffuser Material | Polycarbonate |
| Dimmable | Yes |
| IP Rating | IP65 |
| Voltage | 230V |
| Warranty | 2 Years Standard |
| Extended Warranty | 3 Years Commercial, 5 Years Domestic (If registered) |
| Standards | BS EN 60598:2015, 2-1, 2-2 |
| CE Marked | Yes |
