JCC V50 Pro Retrofit LED Downlight Dimmable IP65 100mm White

The JC-1013-WH V50 Pro retrofit slim-profile dimmable LED downlight is an innovative lighting solution designed to enhance both functionality and aesthetics in various settings. With a compact diameter of 100mm and a sleek 3mm white bezel, this downlight effectively conceals ceiling cut-outs ranging from 70mm to 92mm, making it an ideal choice for retrofitting projects where larger fixtures were previously installed. Its slim design allows for installation in shallow ceiling voids of just 50mm, ensuring that it can fit seamlessly into a variety of architectural configurations.

This versatile downlight offers adjustable colour temperature options of 3000K and 4000K, providing users with the flexibility to create the desired ambience in any space. Rated IP65, the JC-1013-WH is suitable for installation in bathroom zones 1 and 2, ensuring safety and compliance with industry standards. It has been rigorously tested for compatibility with both solid and I-joist ceilings, and its dimmable feature allows for tailored lighting experiences.

Key Features:

• Slim profile 3mm white bezel
• Allows for retrofit where larger downlights were installed previously
• Covers ceiling cut-outs 70-92mm damaged from previous installations
• Low profile design for fitting in shallow 50mm ceiling voids
• Selectable colour temperature: either 3000K (warm white) or 4000K (cool white)
• IP65 rated, suitable for bathroom zones 1 and 2
• Tested for use in solid and I-joist ceilings
• Compatible with dimmers
• 30, 60, 90 minute fire rating
• Made from steel with a polycarbonate lens
• 650 Lumens
• Lumens per Watt: 87lm/W
• LED lifetime of 51,000 hours
• CRI Rating: 80
• Height: 54mm
• Diameter: 100mm
• Voltage: 230V
• Input Electrical Connections: Colour coded Push Fit Terminals LEN Loop In/Loop Out
• Insulation Coverage: Loosely cover with mineral wool insulation
• Guarantee: up to 5 years
